Description
Customer Benefits
Instant return over investment
With a remote operation from the ground, BANDIT avoids rope access and scaffoldings and save inspection time.
Rugged for field use
Built tough to handle demanding conditions and repeated use, BANDIT has been in the field for 10+ years and is the group flagship of motorized crawlers.
Compatible with traceability requirements of most standards
With a precise encoding compatible with most flaw detectors.
Increased job productivity
Easy to maintain with spare parts on the shelf, NDT jobs never get stuck.
Easy to deploy
With quick & adjustable clamp design, BANDIT is a 1-man operated intuitive scanner that is easily set up.
Technical specifications
| Scanner dimensions | 12 x 7 x 4” (30 x 18 x 10 cm) |
| Weight | 10.5 lbs (4.8 kg) |
| Power | Power supply |
| Operating environment | IP65 Water Resistant |
| Encoder resolution | Scanning: 6” / s (150 mm / s) - Indexing: 30” / s (762 mm / s) |
| Scan speed | X-axis: 6”/s (150 mm / s) // Y-axis: 30”/s (762mm / s) |
| 2-axis inspection | ✓ |
| Circumferential OD | From 2” (5 cm) |
| Axial scanning | From 6” (15 cm) |
| Motor controller dimensions | 6.75 x 5 x 2” (30 x 18 x 10 cm) |
| Probe gimbal / fork | Dual 3/8” 5Mhz |
| Umbilical | 100 ft. (30 m) |
| Joystick | ✓ |
